Opis
Input VOLTAGE RANGE 20-36V DC
Output CURRENT RANGE 300-350mA
EFFICIENCY (max.) 95%
WORKING TEMP. -40 ~ + 85℃
STORAGE TEMP., HUMIDITY -55 ~ +125 , 10 ~ 95% RH
RoHs PB free construction
PROTECTION:
OVER TEMPERATURE
SHORT CIRCUIT,
reverse power connection,
reverse polarity at input
EMC EMISSION Compliance to EN55015, FCC part 15 class B
EMC IMMUNITY Compliance to EN61000-4-2,3,4,6,8, light industry level, criteria A
Wymiary 40x50x21mm
Materiał Obudowy ABS
Długośc przewodów Min 200mm
Specyfikacja przewodu OMY 2×0,75
